BEST SELLER

TOPDON · SKU: PXLITE3

TOPDON Phoenix Lite 3 Scan Tool, Bi-Directional Control, Service Functions | PXLITE3

Name: TOPDON Phoenix Lite 3 Scan Tool, Bi-Directional Control, Service Functions | PXLITE3
Brand: TOPDON
SKU: PXLITE3
Price: 799.00 USD
Availability: InStock

★★★★★ 4.8 (127 reviews)

Capacity 9,000 LB

Configuration Symmetric

Max Height 72"

Power 220V

$799.00 $999.00

In Stock

Qty:

📦 Free Shipping to United States ↩️ 30-Day Returns 🔒 Secure Checkout ✓ Authorized Dealer 📞 Expert Support

Technical Specifications

SKU	PXLITE3
Brand	TOPDON
Category	Diagnostic Scanners
Lift Capacity	9,000 lbs
Configuration	Symmetric
Maximum Lifting Height	72 inches
Minimum Ceiling Height	11 feet
Overall Width	140 inches
Overall Height	140 inches
Front Arm Design	3-stage telescoping with rubber pad adapters
Rear Arm Design	2-stage telescoping with rubber pad adapters
Power Requirements	220V, 60Hz, single-phase
Motor Power	2.2 HP
Safety Features	Single-point safety lock release, overhead safety shut-off bar
Lifting Time	50 seconds (floor to full height)
Certifications	ALI/ETL Certified
Warranty	1-year parts, lifetime structural
Shipping Weight	1,180 lbs
Country of Origin	China (manufactured to North American standards)

Phoenix Lite 3 Brings Topology Mapping And Active Tests To Everyday Repairs

Buying a scan tool should not feel like a gamble, but it often does. Many tablets look impressive until you are in the bay and realize you cannot access the modules you need, the menus crawl, or the tool will not support the functions that actually confirm a repair. That is when diagnostics turn into guesswork, parts swapping, or outsourcing the job. Phoenix Lite 3 is built for automotive pros, enthusiasts, and small repair shops that want real full-system access, faster workflows, and modern vehicle support in a compact tablet.

Phoenix Lite 3 runs on an 8 inch touchscreen tablet (1280 x 800) with Android 10, a 4-core 2.0GHz processor, 2GB RAM, and 64GB storage, plus a 12,600mAh battery made for long workdays. It supports full-system diagnostics across 168 plus vehicle makes, so you can scan far beyond basic powertrain codes and check the systems that create the real headaches on modern vehicles. With AutoVIN, topology mapping, and wireless diagnostics via the Phoenix MDCI Bluetooth VCI, it is designed to speed up how you find issues and verify fixes.

Where Phoenix Lite 3 really earns its spot is day-to-day capability: bi-directional active tests, FCA gateway access, modern vehicle communication including CAN FD, plus a deep service function set for common resets and relearns. It also supports advanced workflows such as online coding for select brands, guided functions for supported VAG vehicles, and offline programming for certain makes. If you want a diagnostic tablet that can handle real troubleshooting now and still expand later with add-ons like ADAS, TPMS, EV diagnostics, HD diesel coverage, scope, thermal imaging, and more, Phoenix Lite 3 is built to grow with your workload.

If this model isn’t a match, check our full collection of Diagnostic Scan Tools.

Front side view of the TOPDON Phoenix Lite 3

Benefits of the TOPDON Phoenix Lite 3 Scan Tool

Faster full-system diagnosis | Scan more modules across 168 plus makes and stop guessing.

Better network visibility | Topology mapping shows what is offline and what is failing faster.

More confident repairs | Bi-directional active tests help verify components and circuits.

Stronger late-model support | CAN FD support helps with many 2020 and newer GM and Chrysler vehicles.

More services in one tablet | 35 maintenance functions cover common resets, relearns, and calibrations.

Room to expand | Add ADAS, TPMS, EV, HD diesel, scope, thermal imaging, and more as needed.

Key Features of the TOPDON Phoenix Lite 3 You'll Love:

CAN FD protocol support for modern vehicles: Phoenix Lite 3 supports CAN FD, making it compatible with many newer vehicles that require faster communication standards. This matters on late-model platforms, including many 2020 and newer GM and Chrysler models, where older tools can struggle to connect or run functions reliably. It is a key reason this scanner stays relevant as vehicle networks evolve.
FCA gateway access support for secure diagnostics: Phoenix Lite 3 supports FCA secure gateway access, helping enable full diagnostics on newer FCA vehicles in many cases without separate adapters. That is important for shops and mobile techs that regularly see protected functions on modern vehicles. Coverage can vary by vehicle and region, so verifying your exact year, make, and model is the smartest move.
Full-system diagnostics across 168 plus vehicle makes: Phoenix Lite 3 covers 168 plus makes and can scan essential systems far beyond generic OBD2. This includes major systems like ABS, SRS, engine, and transmission, plus common control modules such as ECM, PCM, EPS, PDM, TPM, BCM, and more. It helps you diagnose the systems that cause real drivability, safety, and communication complaints.
35 maintenance functions for daily shop workflows: The tablet includes 35 service functions to handle common resets and maintenance procedures such as oil reset, EBP reset, suspension reset, and more. It also supports specialized functions within certain systems such as key fob add or replace, battery sensor module learning, and tire pressure sensor learning when the vehicle supports it. This turns the tool into a daily driver, not just a code reader.
Effortless diagnostics anywhere with wireless workflow helpers: AutoVIN can read vehicle information automatically, guided functions can provide step-by-step procedures for supported VAG models, and one-click code reading and clearing speeds up basic workflow. With Bluetooth VCI, you can move around the bay while staying connected. It is built for flexibility when you are diagnosing in tight spaces or managing multiple vehicles.

Applications of the TOPDON Phoenix Lite 3

Compatibility and Coverage (Read This First)

Phoenix Lite 3 supports full-system diagnostics across 168 plus makes, but available functions can vary by year, model, module, region, and software version. This is especially true for online coding, guided functions, secure gateway work, and some bi-directional tests.

Fast Compatibility Check (Recommended):
Send us your Year, Make, and Model and the exact function you need (diagnostics, active tests, service resets, coding, FCA gateway). We’ll confirm coverage before you order.

Talk to a specialist: Contact Us

Phoenix MDCI VCI Specs and Protocol Support

Phoenix Lite 3 includes the Phoenix MDCI Bluetooth VCI, which handles communication between the tablet and the vehicle. VCI quality matters because it impacts connection stability, late-model coverage, and the ability to run higher-level diagnostic workflows where supported.

Protocol support highlights include J2534, DoIP, and CAN FD, which are key for modern vehicle communication and pass-through style workflows where supported.

VCI Component	Details
Phoenix VCI Included	Phoenix MDCI (Bluetooth VCI)
Protocols Supported (Highlights)	J2534, DoIP, CAN FD
Why It Matters	Better late-model coverage, smoother diagnostics, stronger network communication support

Note: Supported functions still vary by vehicle and region. If you are buying for one specific function, send your vehicle info and we will verify coverage.

Programming, Coding, and Advanced Coverage (By Brand)

Online Coding: BMW, VW, Audi, Skoda, SEAT, Porsche.

Guided Function: VW, Audi, Skoda.

Offline Programming: Ford, Mazda, Vauxhall, Opel.

Flash Hidden Function: Benz, BMW, VW, Audi, Skoda, SEAT, Porsche, Jeep, Dodge, Chrystler, Toyota, Honda.

Repair Data: Benz, BMW, VW, Audi, Porsche (11-).

Important: Coverage can vary by year, model, module, region, and software version, even within the same brand. If you send your Year, Make, Model and the exact function you need, we can confirm coverage before you order.

35 Maintenance Services and Daily Workflows

Phoenix Lite 3 is not just for reading and clearing codes. It supports core diagnostic functions like live data streams, active tests, Auto VIN scan, topology display, plus a full set of 35 maintenance services that cover the resets, calibrations, and relearns shops run every week.

1. Oil Reset
3. EPB Reset
5. DPF Regeneration
7. IMMOBILIZER
9. Suspension Reset
11. AFS Headlamp Reset
13. Gear Learning
15. Throttle Adaptation
17. ADBLUE Reset
19. EGR Reset
21. NOx Sensor Reset
23. Seats Calibration
25. Reset Airbag
27. TYPE Reset
29. Clutch Matching
31. Codage ECU
33. IMMO PROG
35. Gateway Module Data Calibration

2. SAS Reset
4. BMS Reset
6. ABS Bleeding
8. Sunroof Reset
10. Gearbox Reset
12. Injector Coding
14. TPMS Reset
16. A/F Reset
18. Coolant Bleed
20. Language Change
22. Odometer Calibration
24. STOP/START
26. Transport Mode
28. Windows Calibration
30. FRM Matching
32. Turbocharging Matching
34. Rainfall light Sensor

Tip: Service coverage can vary by vehicle, module, and region. If one specific service matters for your shop, send your vehicle info and we will confirm it.

Add-On Tools and Expansion Options

Phoenix Lite 3 supports optional add-ons so you can expand your setup when you are ready. Compatible add-ons include TOPDON ADAS mobile packages, thermal imaging cameras, immobilizer and key programming support, a battery and system tester, and a 4-channel oscilloscope.

ADAS Phoenix Mobile Max Package: Mobile ADAS solution for shops that want the most complete package option.
ADAS Phoenix Mobile Deluxe Package: Mid-tier mobile ADAS package option for calibration support.
ADAS Phoenix Mobile Basic Package: Entry-level mobile ADAS package option for calibration support.
ADAS Radar 3-in-1: ADAS radar target solution to support select calibration procedures.
T-Ninja Box: Immobilizer box and key programming add-on for the Phoenix line, including EEPROM support.
BTMobile ProS: 12V battery and system tester that is compatible with the Phoenix line.
Phoenix Scope: 4-channel oscilloscope with accessories that works with Phoenix tools.
TC001 Plus: Dual-lens thermal imaging camera for Android and Windows.
TC001: Thermal imaging camera for Android devices (256x192 resolution).
TS001: Thermal imaging camera for Android devices with 9mm adjustable lens.

Need help choosing add-ons? Tell us what you are servicing most (ADAS work, electrical diagnostics, keys and immobilizers, or inspections) and we will recommend the best add-on combo for your shop.

Software Updates and Ongoing Costs

Phoenix Lite 3 includes 2 years of free software upgrades, and updates can be downloaded directly on the tablet. After the included period, continuing to receive new updates typically requires an end user software update renewal (listed as $495 per year). This renewal is optional, meaning the tool should still function without renewing, but it will not stay current with the latest coverage and updates.

Item	What To Expect
Included Updates	2 years free software upgrades
Update Method	Download and update directly on the diagnostic tablet
Update Renewal (End User)	After 2 years, continued updates are listed as $495 per year (optional)
Warranty	2 years during the initial included period

Quick check: If you tell us the vehicles you service and the exact functions you need, we will help you confirm what is included and what may require a renewal.

Protocols Explained (J2534, DoIP, CAN FD) and Who Needs Them

J2534: Commonly used for pass-through style communication and certain programming workflows on supported vehicles.

DoIP: A modern communication method used on many newer vehicles. DoIP support helps prevent connection limitations as platforms evolve.

CAN FD: A faster version of CAN used on many late-model vehicles. CAN FD support helps the tool communicate properly and run functions more reliably on newer networks.

Who benefits most: Shops and mobile techs working on late-model vehicles, protected diagnostics, and advanced troubleshooting beyond basic code reading.

What’s in the Box

Phoenix Lite 3 tablet
Phoenix MDCI (Bluetooth VCI dongle)
OBDI adapter box transfer line
OBDII extension cable
Cigarette lighter cable
Type-C to USB cable
Battery clamps and cable set
Power adaptor
User manual
Non-standard OBDII adaptor cable kit (10-piece set)
Fuse (φ5*20mm) x 4
Fuse (φ6*30mm) x 2

TOPDON Phoenix Lite 3 OE-Level Scan Tool Specifications
Manufacturer	TOPDON
Product Type	OE-Level Diagnostic Scan Tool Tablet
Model	Phoenix Lite 3 (PXLITE3)
Screen Size	8 inch LCD touch screen
Screen Resolution	1280 x 800
Operating System	Android 10.0
CPU	4-Core 2.0GHz
RAM	2GB
Storage (ROM)	64GB
Battery Capacity	12,600mAh / 3.8V
WiFi	2.4GHz and 5GHz
Camera	Rear 8.0 MP
Tablet Weight	2.61 lb
Product Length	10.16 in
Product Width	7.20 in
Product Height	1.99 in
Working Temperature	32°F to 122°F (0°C to 50°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Communication Interface	Phoenix MDCI (Bluetooth VCI)
Protocols Supported (Highlights)	J2534, DoIP, CAN FD
Vehicle Coverage	168 plus vehicle makes
Maintenance Functions	35
Software Languages	24 Languages: English, German, Spanish, French, Italian, Japanese, Portuguese, Russian, Polish, Turkish, Dutch, Hungarian, Chinese (Traditional), Korean, Finnish, Greek, Slovak, Romanian, Arabic, Croatian, Slovenian, Czech, Danish, Norwegian
Software Updates Included	2 years
Update Renewal Fee (End User)	$495 per year (optional after included period)
Warranty	2 years

Manual

Click to view the Phoenix Lite 3 Manual
